| Main Technical Parameter |
Standard |
| 1 |
Load Capacity(m³/h) |
About 80 |
| 2 |
Vehicle Weight (kg) |
4025 |
| 3 |
Minimum Turning Radius (m) |
5 |
| 4 |
Digging (mm) |
2750 |
| 5 |
Digging (mm) |
1400 |
| 6 |
Digging Depth (mm) |
350 |
| 7 |
Digging Distance (mm) |
1650 |
| 8 |
Unloading (mm) |
1700 |
| 9 |
Unloading Distance (mm) |
1700 |
| 10 |
Grade Ability (°) |
≦18 (Hardstand) |
| 11 |
Traveling Speed (km/h) |
High Speed 5.5/ Low Speed 3 |
| 12 |
Minimum Ground Clearance (mm) |
220 |
| 13 |
Wheel Distance (mm) |
1480 |
| 14 |
Wheelbase (mm) |
1650 |
| 15 |
Rated Working Pressure (MPa) |
12.5 |
| 16 |
Motor Power (Kw) |
22 |
| 17 |
Max. Material Throughput Size (mm) |
810 × 600 × 540 |
| 18 |
Adaptable Roadway Slope (°) |
≦15 |
| 19 |
Adaptable Minimum Roadway Section (m) |
2.2 × 2.2 |
| 20 |
Dimension (Length × × ) |
5600 × 1700 × 1700 |
