| Main Technical Parameter |
Standard |
| 1 |
Load Capacity(m³/h) |
About 80 |
| 2 |
Vehicle Weight (kg) |
3280 |
| 3 |
Minimum Turning Radius (m) |
5 |
| 4 |
Digging (mm) |
2830 |
| 5 |
Digging (mm) |
1920 |
| 6 |
Digging Depth (mm) |
400 |
| 7 |
Digging Distance (mm) |
1550 |
| 8 |
Unloading (mm) |
1700 |
| 9 |
Unloading Distance (mm) |
1700(Can be Lengthened) |
| 10 |
Grade Ability (°) |
≦15(Hardstand) |
| 11 |
Belt Speed (m/min) |
48 |
| 12 |
Traveling Speed (km/h) |
3 |
| 13 |
Minimum Ground Clearance (mm) |
180 |
| 14 |
Wheel Distance (mm) |
1480 |
| 15 |
Wheelbase (mm) |
1610 |
| 16 |
Rated Working Pressure (MPa) |
12.5 |
| 17 |
Motor Power (Kw) |
16.5(15) |
| 18 |
Max. Material Throughput Size (mm) |
800 × 600 × 480 |
| 19 |
Adaptable Roadway Slope (°) |
≦8 |
| 20 |
Adaptable Minimum Roadway Section (m) |
2.2 × 2.2 |
| 21 |
Dimension(Length × × ) |
5600 × 1700 × 1570 |
